HKWY Round open cooling tower

MOQ:

1PC

Payment:

L/C, T/T, West union

Place of Origin:

Jiangsu , China

Delivery Time:

30-40 days

Inquiry

Write a Review

Product features

◆ The whole structure is light and solid, the body and water tank are made of reinforced glass fiber (FRP), never corroded. The surface of the finish with ultraviolet inhibitors, can resist the damage of sunlight;

◆ The special design of PVC water curtain is adopted to prevent spatter, and the spatter loss is less than 0.001%.

◆ Specially designed water disperser, with large diameter and no obstruction, but with good water dispersal effect, is installed in the tower body and free from the pollution of external dust and debris.

◆ Honeycomb vacuum shaped heat sink, interleaving surface with grooves, good heat exchange effect.

◆ Water tank adopts inclined design, easy to clean, less water, low running weight.

◆ Specially designed axial fan with low noise and sufficient air volume.

HKWY minimum water flow chart
Type	(Liters /per sec)
HKWY-17A,17B,17C,17D,17E,17F	1.4-11.1
HKWY-21A,21B,21C,21D,21E,21F,21G,21H	13.9-55.6
HKWY-33A,33B,33C,33D	69.4-118.1
HKWY-42A,42B,42C,42D,42E	138.9-277.8

Technical parameters

Type	Finished Size(mm)		Pneumatic system		Tower Lift	Interface Pipe Diameter（mm）					Weight
Type	Diameter（D）	Height (H)	Power(Kw)	Diameter(Mm)	mH₂O	Inlet pipe	Outlet Pipe	Overflow Outlet Pipe	Supplement Water Pipe	Sewage Outlet Pipe	Net weight	Operating Weight(kg)
HKWY-17A	860	1563	0.12	500	1.5	DN40	DN40	DN25	DN15	DN25	43	78
HKWY-17B	1165	1773	0.18	600	1.7	DN50	DN50	DN25	DN15	DN25	109	285
HKWY-17C	1440	1795	0.75	700	1.8	DN65	DN65	DN25	DN15	DN50	137	505
HKWY-17D	1440	1795	0.75	700	2	DN65	DN65	DN25	DN15	DN50	144	522
HKWY-17E	1800	1845	1.5	900	2	DN80	DN80	DN25	DN20	DN50	228	650
HKWY-17F	1800	1845	1.5	900	2	DN80	DN80	DN25	DN20	DN50	277	719

Type	Finished products size(mm)		Pneumatic system		Tower Lift	interface pipe diameter（mm）					Weight
Type	Diameter（D）	Height (H)	Power(kw)	Diameter(mm)	mH₂O	Inlet pipe	outlet pipe	Overflow outlet pipe	supplement water pipe	sewage outlet pipe	Net weight(kg)	Operating Weight(kg)
HKWY-21A	1900	2140	1.5	1200	2	DN100	DN100	DN25	DN20	DN50	337	798
HKWY-21B	2410	2365	2.2	1500	2.5	DN100	DN100	DN25	DN20	DN50	474	1205
HKWY-21C	2730	2330	2.2	1500	3	DN125	DN125	DN25	DN25	DN50	524	1336
HKWY-21D	3050	2465	3.7	1800	3	DN125	DN125	DN50	DN25	DN50	702	3212
HKWY-21E	3050	2465	3.7	1800	3.1	DN125	DN125	DN50	DN25	DN50	855	3415
HKWY-21F	3280	2405	5.5	2400	3.3	DN150	DN150	DN50	DN32	DN50	1022	3661
HKWY-21G	3760	2740	5.5	2400	3.6	DN200	DN200	DN50	DN32	DN50	1172	3885
HKWY-21H	4160	2835	7.5	2400	3.6	DN200	DN200	DN50	DN32	DN50	1331	4125

Type

Finished products size(mm)

Pneumatic system

Tower Lift

interface pipe diameter（mm）

Weight

Diameter（D）

Height (H)

Power(kw)

Diameter(mm)

mH₂O

Inlet pipe

outlet pipe

Overflow outlet pipe

supplement water pipe

sewage outlet pipe

Net weight(kg)

Operating Weight(kg)

HKWY-33A

4600

3370

7.5

2400

4.1

DN200

DN80

DN32

DN50

1560

5690

HKWY-33B

4600

3375

3000

4.3

DN200

DN80

DN32

DN50

1902

6145

HKWY-33C

4870

4264

3000

4.4

DN250

DN80

DN40

DN50

2165

6837

HKWY-33D

5580

3990

3400

5.1

DN250

DN80

DN40

DN50

2909

8052

Type	Finished products size(mm)		Pneumatic system		Tower Lift	interface pipe diameter（mm）					Weight
Type	Diameter（D）	Height (H)	Power(kw)	Diameter(mm)	mH₂O	Inlet pipe	outlet pipe	Overflow outlet pipe	supplement water pipe	sewage outlet pipe	Net weight(kg)	Operating Weight(kg)
HKWY-42A	6550	4200	15	3400	5.1	DN250	DN250	DN100	DN50	DN50	3411	11734
HKWY-42B	6550	4200	22	3400	5.8	DN300	DN300	DN100	DN50	DN50	3963	12690
HKWY-42C	6550	4935	22	3600	6.1	DN300	DN300	DN100	DN50	DN50	4512	13465
HKWY-42D	7600	5315	30	4270	6.3	DN300	DN300	DN100	DN65	DN65	4650	14500
HKWY-42E	8430	5605	37	4200	6.5	DN300	DN300	DN100	DN65	DN65	5500	21500

Remarks:

1.Design conditions: Inlet temperature t1=37℃, outlet temperature t2=32℃, wet bulb temperature t=28℃, dry bulb temperature O=31.5℃, barometric pressure P=9.94×104Pa

2.The above technical parameters are for reference only. Our company reserves the right to modify the product appearance and technical parameters due to the continuous upgrading of technology
